U.S. Flush-decker destroyers

Flush-decker destroyers (6 Caldwell, 110 or 111 Wickes and 155 Clemson class ships).
Type: Destroyer.

Flush-decker destroyers, also known as “four-pipers” or “four-stackers,” were a class of destroyers built for the United States Navy during and shortly after World War I. These ships were characterized by their distinctive design features and played a significant role in naval operations during the early 20th century.

Overview

Flush deck: The ships had a continuous main deck from bow to stern, giving them their “flush-decker” name.
Four stacks (funnels): Most of these destroyers had four prominent smokestacks, leading to their “four-piper” nickname.
High speed: They were designed for high-speed operations, typically capable of speeds over 30 knots.
Light armament: Equipped with 4-inch guns and torpedo tubes.
Large numbers: Over 270 of these destroyers were built between 1917 and 1922.

World War I: Many flush-deckers were built to combat German U-boats during WWI, though most were completed after the war ended.
Interwar period: These ships formed the backbone of the U.S. destroyer fleet during the 1920s and 1930s.
World War II: Despite being outdated, many flush-deckers served in various roles during WWII, including convoy escort, anti-submarine warfare, and as fast transports.
Lend-Lease: Fifty of these destroyers were transferred to the British Royal Navy in 1940 as part of the Lend-Lease program.
Post-war: Most were decommissioned and scrapped after WWII, though some were converted for other uses or transferred to other navies.

Notable classes of flush-decker destroyers:
1. Caldwell class (6 ships)
2. Wickes class (111 ships)
3. Clemson class (156 ships)

While flush-decker destroyers were considered obsolete by World War II standards, they played a crucial role in the development of destroyer design and tactics, and their large numbers made them a significant part of naval operations in the first half of the 20th century.

History

The first fifty of these ships were authorized as part of the US Navy’s 1916 program, which was designed to prepare for inevitable involvement in World War One. The main design criterion was to keep pace with the planned new battlecruisers and cruisers, which necessitated a speed of 35 knots, which could only be achieved by a fifty percent increase in power, which meant more and heavier machinery in a relatively small hull.
The result was the famous ‘flush-decker’ which was built at eight yards: Bath iron Works (8), Chesapeake Nay Yard (1), Cramp (21), Fore River (26), Mare Island Navy Yard (8), New York Sip Building (10), Newport News (11) and Union Iron Works (26 ships).
The ships were built to two slightly different detailed designs, one prepared by Bethlehem Steel for its Fore River and Union Iron Works shipyards, the other by Bath Iron Works for the remainder, this latter being dubbed, albeit unofficially, as the ‘Liberty’ type.
Only a few were completed in time to take part in World War One, but the type provided the bulk of the US Navy’s destroyer force throughout the 1920s and 1930s, although twenty-five were disposed of, mainly due to mechanical shortcomings. Fourteen were converted to fast mine layers in 1920, all their torpedo tubes being removed to provide space for mines. Even so, a large number remained in 1939, and although elderly they still played a full part in the Second World War.
Twenty-seven Wickes class destroyers were handed over to Royal Navy and RCN in 1940 (plus 3 of the early Caldwell class and 20 of the final Clemson class) in order to provide those two navies with desperately needed escorts. A number were lost in the war and the survivors were scrapped 1946-47.

Users: US Navy, British Royal Navy, Canada.

---

Specifications for Wickes class

Specifications:

Wickes class	specification
Type	destroyer
Displacement	1,090 tons
Displacement (full loaded)	1,247 tons
Length	314.3 ft
Beam	30 ft 8 in
Draught	9.2 ft
Boiler	4 boilers (Yarrow, Thornycroft or White)
Propulsion	Parsons steam-turbines plus geared cruising turbine or Westinghouse with 2 shafts
Power	24,200-27,000 hp
Bunkerage	295 tons petrol
Speed	35 kts
Range	2,500 nm at 20 kts
Complement	114 - 122

Armament:

Wickes class	specification
Main Armament	4 x 4in (102mm) guns
Secondary Armament	-
Anti-Aircraft	1 x 3in (76mm) or 2 x 1-pdr AA
Torpedo tubes	12 x 21in (533mm)
Anti-Submarine	? (on photos from British conversations at minimum 2 depth-charge racks visible)
Mines	-
Aircrafts	-

Service statistics:

Flush-decker destroyers	figures
Completed Caldwell class	6 ships 1916-17
Completed Wickes class	110 or 111 ships 1917-1919
Completed Clemson class	155 ships 1918-1921
Remaining Caldwell class	1 rebuild as fast troop transport, 3 to Royal Navy in 1940, 2 scrapped before 1941
Remaining Wickes class	32 scrapped before 1941, 27 to Royal Navy in 1940, 14 converted as fast minelayers, 6 converted for other tasks, 12 rebuild as fast troop transport from 1942
Remaining Clemson class	64 scrapped before 1941, 4 sold, 29 converted for other tasks, 20 to Royal Navy in 1940, 8 rebuild as fast troop transports from 1942
	total 17 war losses during WW2, all others scrapped in 1946-1947

---

3D Model of Wickes class

---

References and literature

Fighting Ships of the World (Antony Preston)
Kriegsschiffe von 1900 bis heute – Technik und Einsatz (Buch und Zeit Verlagsgesellschaft)
The Illustrated Directory of Warships from 1860 to the present day (David Miller)
Flotten des 2. Weltkrieges (Antony Preston)
Die Schlacht im Atlantik (Andrew Kershaw)
The Encyclopedia of Weapons of World War II (Chris Bishop)
