Lee-Enfield Rifle 303 No.4 Mark 1

British infantry rifle Lee-Enfield No.4 Mark 1 of WW2.
History, development, service, specifications, pictures and 3D model.

British Enfield rifle No.4 in action
British Enfied rifle No.4 in action protecting a Bren gunner. This revised specimen was the best of its type and was still in use by NATO forces.

Lee-Enfield rifle 303 No.4 Mark 1.
Type: British infantry rifle.

Lee-Enfield Rifle

History

The well-known Lee-Enfield rifle began its service with the British Army in 1895 and ran into some 27 different models before being replaced by a self-loader in 1957. The most famous model was probably the Mark 3, the ‘Short’ Lee-Enfield, so-called because it introduced a new idea into military rifles. Prior to its introduction (in 1903) it was customary to produce two rifle type weapons, one a long rifle for infantry use and one a short carbine for cavalry and other mounted troops such as engineers and artillery. The ‘Short’ Lee-Enfield was shorter than a normal ‘long’ rifle, and longer than a carbine, and thus it was possible to standardize on one weapon for all branches of the Army.

Excellent as the Mark 3 was, it had some drawbacks, and the major one was that its manufacture was time-consuming, demanding much machining and hand­fitting. The other principal complaint was that the nature and location of the back sight (an open-topped U in front of the chamber) made it difficult to master quickly. Because of these points, work began immediately after the Armistice in 1918 to try to develop a rifle which retained the Lee-Enfield’s many virtues’ ­ robustness, speed of operation, reliability – but which had better sights and was easier to make. The first attempt was the ‘No.1 Mark 5’ (a new system of nomenclature had been adopted after the war) which was little more than a Mark 3 with an aperture sight at the rear of the receiver. It was never adopted as a service weapon. The design was then simplified into the ‘No.1 Mark 6’ which used a heavier barrel, a new design of bolt, less woodwork, and a projecting muzzle on to which a spike bayonet could be fixed. This too was never adopted, but with a little more improvement it became the ‘No.4 Mark 1’, the standard WW2 rifle.

The No.4 rifle was much like the earlier Mark 6, but there were numerous small changes which simplified production. It was first issued late in 1939, though not officially adopted until 13 February 1941. Well over one million were made from November 1939 onwards during the Second World War, both in Britain and across the Atlantic in the USA and Canada, and after some misgivings by old soldiers who missed the immaculate finish of the Mark 3, the No.4 became liked and trusted in its turn. It remained in service as a sniping rifle, using 7.62 mm NATO ammunition.

Altogether over 5 million Lee-Enfield rifles from the model No 1 Mk III, Mk III*, No 4 Mk I, No 5 Mk I (100,000) and No 4 Mk I (T) sniper-rifles (25,000) were produced and used in both World Wars.


Pictures Lee-Enfield Rifle


Specifications Lee Enfield rifle 303 No.4 Mark 1

Specifications:

Lee Enfield rifle 303 No.4 Mark 1 Specification
TypeInfantry rifle
Caliber.303in
Length44.43in
Weight9lb 1oz
Barrel 25.19 in long, 5 grooves, right hand twist
Feed system10-round detachable box magazine
System of operationLee turn-bolt
Muzzle velocity 2,400 feet/sec
Rate of fire up to 10 rounds in 10 seconds

Service statistics:

Lee Enfield rifle 303 No.4 Mark 1 figures
Manufactures Royal Ordonance Factory, Fazakerley; Royal Ordonance Factory, Maltby; Birmingham Small Arms Co., Tyseley; Savage Arms Co., Chicopee Falls, Mass., USA; Long Branch Arsenal, Ontario, Canada
Early Production since 1895; Mark 3 1903
Production delivery No.4 Mark 1 1941
Final delivery1957
Production figure in World War 2 5+ million


3D Model Lee Enfield Rifle 303 No.4 Mark 1


References and literature

The Encyclopedia of Weapons of World War II (Chris Bishop)
The Encyclopedia of Infantry Weapons of World War II (Ian V.Hogg)
Infanterie im 2. Weltkrieg (J.B.King, John Batchelor)
Illustriertes Lexikon der Waffen im 1. und 2. Weltkrieg (V. Dolinek, V. Francev, J. Sach)
